Others > Other > Other > Heavy Duty Rugged LCD Monitor Stainless Steel Waterproof Touch Screen IP66 IP67
Stock in Djbouti
In StockFast Dispatch
In addition to the products displayed on this page, the supplier still has other special products ( which are not displayed to the public yet ), you can contact supplier to find them in your Buyer Center by getting approval from supplier

Heavy Duty Rugged LCD Monitor Stainless Steel Waterproof Touch Screen IP66 IP67

Min Order:

  • PZ68375F7
    -
    +
    CTN(1CTN=1PCS)
Total Cost :
$0.00
Add to Cart Contact Supplier
STS ( Smart Transaction System ) : Fulfill your order by system and secure your transaction
Logistics Services : Dropshipping to your end consumers      Shippping to your local warehouse

Overview

Brand Name
ITD
Model Number
ITD**CMT1IPS1
Certification
CE, FCC, RoHS
Place of Origin
China
MOQ
1pcs
Price
TBA
Payment Terms
T/T, Western Union, Paypal
Supply Ability
10000PCS/Month
Delivery Time
5-15 Business Days
Packaging Details
1-5pcs/CTN, Safe, Firm
Housing Material
Stainless Steel/Aluminum Alloy Chassis
Color
Silver/Black
Housing Type
VESA Mount/Panel Mount
Application
Outdoor Display, Food Industry, Harsh Envrionment
Operating Temperature
-10~60℃(-20~70℃ optional)
Operating Humidity
10%-90% (Non Condensing)
MTBF
50000H
Failure Rate
0.3%
Warranty
1 Year for TFT Panel and 2 Years for others

Product Details

IP66 IP67 fully sealed heavy duty stainless steel waterproof touch screen monitor


ITD range of Full IP66/67 Touchscreen Monitors consists of a stainless steel or aluminum alloy rugged enclosure complying with IP65 protection standards from all directions. They are proof of dust and water drops and resistant stainless-steel fronts with polished surface for easy cleaning, which are built for demanding applications with high industrial requirement, such as in food processing, chemical, pharmaceutical applications in harsh environment.rmaceutical applications in harsh environment.


FEATURES

-Exceptional quality and highly engineered industrial heavy duty monitors
-Optional touchscreens like resistive and PCAP
-Ruggedized levels of NEMA 12, 4X, 4, IP52, IP56, IP65 ratings from all directions
-Solid steel and stainless steel or aluminum alloy enclosures
-IP65 sealed, Full IP65 I/O connectors protect from any particles, water, and corrosive agents
-Accuracy in high-use applications
-Long lasting product cycle for continuity thru all phases of project


Applications for Rugged Touchscreen LCD Monitors

- Food processing plant automation control

- Kitchen application

- Chemical plant or laboratory

- Liquor Factory

- Clinical area / pharmaceutical / medical

- Operating and monitoring in Oil, Gas & Energy industry

- Industrial automation control in slaughtering house

- Railway/Transportation

ModelITD07CMG1IPS1ITD08CMG1IPS1ITD09CMG1IPS1ITD10CMG1IPS1
Size7”8.4”9.7”10.4”
Active Area152.4(W) x 91.44(H)170.4(W) x 127.8(H)196.608(W) x 147.456(H)211.2(W) x 158.4(H)
Pixel Pitch0.19050.2130.1920.264
Contrast Ratio500:1600:1500:1500:1
Resolution800 x 480 or 1024 x 600800 x 6001024 x 768800 x 600 or 1024 x 768
Brightness300nits250nits350nits300nits
Viewing Angles80/80/80/8080/80/80/6080/80/80/8070/70/60/70
Response Time30ms30ms25ms35ms
Colors262K262K262K262K
BacklightLEDLEDLEDLED
ModelITD12CMG1IPS1ITD15CMG1IPS1ITD17CMG1IPS1ITD19CMG1IPS1
Size12.1”15”17”19”
Active Area246.0(H) x 184.5(V)304.12(H)x 228.09(V)337.92(H) x 270.33(V)376.32(H) x 301.06(V)
Pixel Pitch0.30750.2970.2640.294
Contrast Ratio700:1700:11000:11000:1
Resolution800 x 600 or 1024 x 7681024 x 7681280 x 10241280 x 1024
Brightness300nits250nits250nits250nits
Viewing Angles70/70/60/7080/80/60/7085/85/80/8085/85/80/80
Response Time35ms35ms5ms5ms
Colors262K16.2M16.7M16.7M
BacklightLEDLEDLEDLED
ModelITD21CMG1IPS1ITD24CMG1IPS1ITD27CMG1IPS1ITD32CMG1IPS1
Size21.5”24”27”32”
Active Area476.64(H)x248.25(V)531.36(H)x298.89(V)597.6(H)x336.15(V)698.4(H)x392.85(V)
Pixel Pitch0.2480.27680.31140.3638
Contrast Ratio1000:11000:11000:11200:1
Resolution1920 x 10801920x10801920x10801920x1080
Brightness250nits300nits300nits400nits
Viewing Angles85/85/80/8089/89/89/8989/89/89/8989/8/9/89/89
Response Time5ms5ms5ms8ms
Colors16.7M16.7M16.7M16.7M
BacklightLEDLEDLEDLED
ModelITD43CMG1IPS1ITD49CMG1IPS1ITD55CMG1IPS1ITD65CMG1IPS1
Size43”49”55”65”
Active Area930.24(H)x523.26(V)1073.78mm(W)×604mm(H1209.6(H)x680.4(V)1428.48(H)x803.52(V)
Pixel Pitch0.49020.559260.630.744
Contrast Ratio1200:11100:11400:11400:1
Resolution1920x10801920x10801920 x 10801920 x 1080
Brightness400nits450nits400nits400nits
Viewing Angles89/89/89/8989/89/89/8989/89/89/8989/89/89/89
Response Time12ms6ms8ms8ms
Colors16.7M16.7M16.7M16.7M
BacklightLEDLEDLEDLED

SPECIFICATION

Input Signal ConnectorsVGA (Waterproof Connector)
Power (Waterproof Connector)
USB/RS232 (Waterproof Connector) Optional for Touch Connection
Power InputExternal DC 12V for 7”~24”; Internal AC 110-240V for 27”~65”
Power ConsumptionTBA
Operating Temperature-10~60℃ for 7”~24”; 0~50℃ for 27”~65”
Storage Temperature-20~70℃
Operating Humidity10%~90% (Non Condensing)
Order InformationFull IP65/IP66 stainless steel monitor with tempered glass/ITD**CMG1IPS1
Full IP65/IP66 stainless steel monitor with Resistive touch/ITD**CMT1IPS1
Full IP65/IP66 stainless steel monitor with PCAP touch/ITD**CMT5IPS1
Full IP65/IP66 aluminum alloy monitor with tempered glass/ITD**CMG1IPA1
Full IP65/IP66 aluminum alloy monitor with Resistive touch/ITD**CMT1IPA1
Full IP65/IP66 aluminum alloy monitor with PCAP touch/ITD**CMT5IPA1
Full IP65/IP66 steel monitor with tempered glass/ITD**CMG1IPX1
Full IP65/IP66 steel monitor with Resistive touch/ITD**CMT1IPX1
Full IP65/IP66 Steel Monitor with PCAP touch/ITD**CMT5IPX1
Full IP67 stainless steel monitor with tempered glass/ITD**CMG1IPS7
Full IP67 stainless steel monitor with Resistive touch/ITD**CMT1IPS7
Full IP67 stainless steel monitor with PCAP touch/ITD**CMT5IPS7
